LG GRPA062 Stadium LED

Tech Specification:

Physical Parameter

• Pixel Pitch (mm) 6.25
• Pixel Configuration Single SMD
• Module Resolution (W x H) 64 x 48
• Module Dimensions (W x H, mm) 400 x 300
• Weight per Module (kg) 1.46
• Cabinet Resolution (W × H) 128 x 144
• Cabinet Dimensions (W × H × D, mm) 800 x 960 x 120 (Screen 800 x 900)
• No. of Modules per Cabinet (W × H) 2 x 3
• Cabinet Surface Area (m²) 0.72
• Weight per Cabinet (kg/cabinet) 20
• Weight per Square Meter (kg/m²) 22.5
• Physical Pixel Density (pixels/m²) 25,600
• Flatness of Cabinet ±0.5 mm
• Cabinet Material Aluminum
• Service Access Top

Optical Specifications

• Max. Brightness (After Calibration) 6,000
• Color Temperature 3,200 ~ 9,300 (Default 6,000)
• Visual Viewing Angle (Horizontal/Vertical) 160 × 120
• Brightness Uniformity 97%
• Color Uniformity ±0.003Cx,Cy
• Contrast Ratio 6,000：1
• Processing Depth (bit) 16 (HDR10, HDR10 Pro)

Electrical Specifications

• Power Consumption (W/Cabinet, Max.) 720
• Power Consumption (W/Cabinet, Avg.) 280
• Power Consumption (W/m², Max.) 750
• Heat Dissipation (BTU/h/Cabinet, Max.) 1,966
• Heat Dissipation (BTU/h/Cabinet, Avg.) 765
• Heat Dissipation (BTU/h/㎡, Max.) 2,048
• Power Supply (V) 100 to 240
• Frame Rate (Hz) 50 / 60
• Refresh Rate (Hz) 7,680

Operation Conditions

• Lifetime (Hours to Half Brightness) 100,000
• Operating Temperature (°C) -20℃ to +50℃
• Operating Humidity 10~90%RH
• IP rating Front / Rear IP65 / IP65
